5203 Series Motor (1:1 Ratio, 24mm Length 8mm REX Shaft, 6000 RPM, 3.3 – 5V Encoder)

70,56 (57,84 + IVA)

Checking...

SKU: 5203-2402-0001 Category:

5203 Series Motor (1:1 Ratio, 24mm Length 8mm REX Shaft, 6000 RPM, 3.3 – 5V Encoder)

70,56 (57,84 + IVA)

Checking...

SKU: 5203-2402-0001 Category:

European Costumers

Motor Size RS-555
Motor Type Brushed DC
Nominal Voltage 12VDC
Output Shaft 8mm REX, 24mm Length
Gearbox Style Planetary
Gear Ratio 1:1
Gear Material Steel
No-Load Speed @ 12VDC 6,000 RPM
No-Load Current @12VDC 0.25A
Stall Current @12VDC 9.2A
Stall Torque @12VDC 1.47 kg.cm (20.45 oz-in)
Wire Length 470mm (including connectors)
Wire Gauge 16AWG
Motor Connector Type 3.5mm FH-MC Bullet Connectors
Encoder Connector Type 4-Pos JST XH [FH-MC]
Encoder Type Relative, Quadrature
Encoder Sensor Type Magnetic (Hall Effect)
Encoder Voltage Range 3.3 – 5VDC
Encoder Resolution 28 PPR at Output Shaft
Weight 396g
IP Patents Pending
