Specifications
Dimensions | 0.89" x 0.45"x 0.94" (22.8 x 11.6 x 24mm) |
---|---|
Product Weight | 0.28oz (8g) |
Output Shaft Style | 15 tooth (A1) spline |
Voltage Range | 4.8V - 6.0V |
No-Load Speed (4.8V) | 0.18 sec/60° |
No-Load Speed (6.0V) | 0.14 sec/60° |
Stall Torque (4.8V) | 16.66 oz-in. (1.2kg.cm) |
Stall Torque (6.0V) | 20.83 oz-in. (1.5kg.cm) |
Max PWM Signal Range (Standard) | 615-2390μsec |
Travel per µs (out of box) | .114°/μsec |
Max Travel (out of box) | 203° |
Pulse Amplitude | 3-5V |
Operating Temperature | -20°C to +60°C |
Current Drain - idle (4.8V) | 5.4mA |
Current Drain - idle (6.0V) | 5.5mA |
Current Drain - no-load (4.8V) | 150mA |
Current Drain - no-load (6V) | 180mA |
Continuous Rotation Modifiable | No |
Direction w/ Increasing PWM Signal | Clockwise |
Deadband Width | 8µs |
Motor Type | Coreless |
Internal Feedback Style | 5KΩ Potentiometer |
Output Shaft Support | Outer case serves as bearing |
Gear Type | Straight Cut Spur |
Gear Material | Nylon |
Wire Length | 6.29" (160mm) |
Wire Gauge | 28AWG |
