Nema 11 with gearmotor

Motore passo passo con motoriduttore. A differenza dei motori passo passo tradizionali questo modello è in grado di sviluppare una coppia di 6Nm

69,38 (56,87 + IVA)

Available on back-order

SKU: 11HS12-ST-0674D-PG27 Categories: , Tag:
Nema 11 stepper motor with gear motor
Gearbox Specification
Backlash at No-load(Max.°) 1
Efficiency 81%
Gear Ratio 26.85:1
Gearbox Length(mm) 35
Gearbox Type Planetary
Max. Permissible Torque(Ncm) 300
Max. Permissible Torque( 424.8
Moment Permissible Torque(Ncm) 500
Moment Permissible Torque( 708.1
Shaft Maximum Axial Load(N) 5
Shaft Maximum Radial Load(N) 25
Motor Specification
Inductance(mH) 4
Lead Length(mm) 300
Motor Nema Size Nema 11
No. of Lead 4
Phase Resistance(ohm) 5.6
Rated Current(A) 0.67
Shaft Diameter(mm) 6
Shaft Length(mm) 18
Bipolar/Unipolar Bipolar
Holding Torque w/o Gearbox(Ncm) 7
Holding Torque w/o Gearbox( 9.9
Motor Length(mm) 31.5
Single Shaft/Dual Shaft Dual Shaft
Shaft Type D-Cut
Physical Specification
Weight(g) 200
