Stroke | 3.9" |
---|---|
Stall Thrust (7.5V) | 4.9lb |
No-Load Speed (7.5V) | 1.0in/s |
Static Load | 45.0lb powered on, 2.7lb powered off |
Voltage Range (Recommended) | 4.5 - 7.5 V |
Weight | 2.50 oz |
Pulse Amplitude | 3 - 5 V |
Operating Temperature | -10°C ~ +50°C |
Motor Type | Brushed DC |
Feedback Style | 11 KΩ / inch |
Wire Length | 11.8" |
Wire Gauge | 26 AWG |
Connector Type | Male Servo Connector |
Gear Ratio | 50:1 |
Current Drain (No-Load) | 7.2 mA |
Current Drain (Stall) | 460 mA |
IP Rating | IP54 |
Duty Cycle | 20% |
Potentiometer Linearity | Less than 2.00% |
