Stroke | 5.5" |
---|---|
Pulse Amplitude | 3 - 5 V |
Operating Temperature | -10°C ~ +50°C |
Motor Type | Brushed DC |
Feedback Style | 16 KΩ / inch |
Wire Length | 300 mm |
Weight | 3.50 oz |
Wire Gauge | 26 AWG |
Voltage Range (Recommended) | 4.5 - 7.5 V |
Speed (No Load)* | 8 mm per second |
Connector Type | Male Servo Connector |
Gear Ratio | 150:1 |
Dynamic Thrust* | 200 N |
Static Load | 250 N powered on, 102 N powered off |
Current Drain (Stall)* | 650 mA |
IP Rating | IP54 |
Duty Cycle | 20% |
