Optimized for torque
€21,46 (€17,59 + IVA)
| Weight | 52g |
|---|---|
| Output Shaft Style | 25 Tooth Spline |
| Voltage Range | 4.8V - 6.0V |
| No-Load Speed (4.8V) | 0.21 sec/60° (48RPM) |
| No-Load Speed (6.0V) | 0.19 sec/60° (55RPM) |
| Stall Torque (4.8V) | 65 oz-in (4.68 kg.cm) |
| Stall Torque (6.0V) | 75 oz-in (5.40 kg.cm) |
| No-Load Current (4.8V) | 80mA |
| No-Load Current (6.0V) | 90mA |
| Stall Current (4.8V) | 800mA |
| Stall Current (6.0V) | 1,000mA |
| Max PWM Range | 600-2400µsec |
| Travel per μsec | 0.105°/μsec |
| Max Rotation | 189° |
| Pulse Amplitude | 3-5V |
| Deadband Width | 5µsec |
| Motor Type | Brushed DC |
| Feedback Style | 5KΩ Potentiometer |
| Output Shaft Support | Dual Ball Bearing |
| Gear Material | Steel |
| Wire Length | 11.81" (300mm) |
| Wire Gauge | 22AWG |
| Connector Type | 3-Pos TJC8 Servo Connector [MH-FC] |
| Servo Size | Standard |
| Direction with Increasing PWM Signal | Clockwise |
