2000 Series Dual Mode Servo (25-3, Speed)

SKU: 2000-0025-0003 Category:

The servo can be configured to work in both traditional and continuous rotation modes.

Using programmer 3102-0001-0001

44,88 (36,79 + IVA)

Checking...

Download

Drawings
Weight 58g
Gear Ratio 135:1
Output Shaft Style 25 Tooth Spline
Voltage Range 4.8V ~ 7.4V
No-Load Speed (4.8V) 0.11 sec/60° (90RPM)
No-Load Speed (6.0V) 0.09 sec/60° (115RPM)
No-Load Speed (7.4V) 0.07 sec/60° (145RPM)
Stall Torque (4.8V) 7.9 kg.cm (110 oz-in)
Stall Torque (6.0V) 9.3 kg.cm (130 oz-in)
Stall Torque (7.4V) 10.8 kg.cm (150 oz-in)
No-Load Current (4.8V) 190mA
No-Load Current (6.0V) 200mA
No-Load Current (7.4V) 230mA
Stall Current (4.8V) 2000mA
Stall Current (6.0V) 2500mA
Stall Current (7.4V) 3000mA
Max PWM Range (Default) 500 - 2500μsec
Max PWM Range (Continuous) 1000 - 2000μsec
Travel per µsec (Default) 0.15°/μsec
Max Travel (Default) 300°
Pulse Amplitude 3-5V
Direction Clockwise w/ Increasing PWM Signal
Deadband Width 4μsec
Motor Type Brushed DC
Feedback Style 5KΩ Potentiometer
Output Shaft Support Dual Ball Bearing
Gear Material Steel
Wire Length 300mm
Wire Gauge 22 AWG
Connector Type 3-Pos TJC8 Servo Connector [MH-FC]
