560 lb Thrust Super Duty Linear Actuator (SDA4-263)

SKU: SDA4-263 Categories: , ,

645,38

Checking...

560 lb Thrust Super Duty Linear Actuator (SDA4-263)

Product Weight 158.9 oz
Voltage Range (Recommended) 6V - 12V
Operating Temperature -25°C ~ +65°C
Speed (No Load)* 2.63” per second
Speed (Max Load)* 1.85” per second
Dynamic Thrust* 560 lbs
Static Load 3,050 lbs
Current Drain (No-Load)* 3A
Motor Type 3 Pole Ferrite
Feedback Style 10KΩ Potentiometer
Potentiometer Tolerance ± 5%
Potentiometer Linearity ± 0.25%
Feedback Density 1.66KΩ / inch
Gear Ratio 5:1
Gear Material Metal Gear Train
Gearbox Style Straight Cut Spur
Wire Length 12"
Ingress Protection (IP) IP54
Duty Cycle 25% (25% on, 75% off)
Lead Screw Type Ball Screw
Lead Screw Material Steel
