485 RPM Econ Gear Motor (638356)

21,03 (17,24 + IVA)

SKU: 638356 Category:
Checking...
Voltage (Nominal) 12V
Voltage Range (Recommended) 6V - 18V
Speed (No Load)* 485 rpm
Current (No Load)* 0.10A
Current (Stall)* 3.8A
Torque (Stall)* 106.28 oz-in (7.65 kgf-cm)
Gear Ratio 20:1
Gear Material Metal
Gearbox Style Straight Cut Spur
Motor Type DC
Output Shaft Diameter 4mm (0.1575”)
Output Shaft Style D-shaft
Output Shaft Support Bushing
Electrical Connection Male Spade Terminal
Operating Temperature -10°C ~ +60°C
Mounting Screw Size 3mm
Product Weight 0.19lb (3.05oz)
