56 RPM Econ Gear Motor (638348)

SKU: 638348 Category:

21,03 (17,24 + IVA)

Checking...

[et_pb_section bb_built="1"][et_pb_row][et_pb_column type="4_4"][et_pb_text]

Voltage (Nominal) 12V
Voltage Range (Recommended) 6V - 18V
Speed (No Load)* 56 rpm
Current (No Load)* 0.11A
Current (Stall)* 3.85A
Torque (Stall)* 914.01 oz-in (65.82 kgf-cm)
Gear Ratio 171:1
Gear Material Metal
Gearbox Style Straight Cut Spur
Motor Type DC
Output Shaft Diameter 4mm (0.1575”)
Output Shaft Style D-shaft
Output Shaft Support Bushing
Electrical Connection Male Spade Terminal
Operating Temperature -10°C ~ +60°C
Mounting Screw Size 3mm
Product Weight 0.20lb (3.25oz)

[/et_pb_text][et_pb_image _builder_version="3.19" src="https://www.steplab.net/wp-content/uploads/2018/12/638340_to_638344.png?x71106&x71106" /][/et_pb_column][/et_pb_row][/et_pb_section]
