624 RPM Premium Planetary Gear Motor w/Encoder (638304)

SKU: 638304 Categories: ,

50,31 (41,24 + IVA)

Checking...
Voltage (Nominal) 12V
Voltage Range (Recommended) 3V - 12V
Speed (No Load)* 624 rpm
Current (No Load)* 0.19A
Current (Stall)* 4.9A
Torque (Stall)* 41.7 oz-in (3 kgf-cm)
Gear Ratio 19.225:1
Gear Material Metal
Gearbox Style Planetary
Motor Type DC
Output Shaft Diameter 4mm (0.1575”)
Output Shaft Style D-shaft
Output Shaft Support Dual Ball Bearings
Operating Temperature -10 ~ +60°C
Mounting Screw Size M2 x 0.4mm
Product Weight 3.55oz
Encoder: Cycles Per Revolution (Motor Shaft) 3
Encoder: Cycles Per Revolution (Output Shaft) 57.675
Encoder: Countable Events Per Revolution (Motor Shaft) 12
Encoder: Countable Events Per Revolution (Output Shaft) 230.7
Encoder Type Relative, Quadrature
Encoder Sensor Type Magnetic (Hall Effect)
Encoder Sensor Input Voltage Range 2.4 - 26V
Encoder Sensor Output Pulse Amplitude ~= Sensor Input Voltage
