Voltage (Nominal) | 12V |
---|---|
Voltage Range (Recommended) | 3V - 12V |
Speed (No Load)* | 26 rpm |
Current (No Load)* | 0.21A |
Current (Stall)* | 4.9A |
Torque (Stall)* | 583 oz-in (42 kgf-cm) |
Gear Ratio | 455.185:1 |
Gear Material | Metal |
Gearbox Style | Planetary |
Motor Type | DC |
Output Shaft Diameter | 4mm (0.1575”) |
Output Shaft Style | D-shaft |
Output Shaft Support | Dual Ball Bearings |
Electrical Connection | 6-pin Female Header Row (0.1", 2.54mm Pitch) |
Operating Temperature | -10°C ~ +60°C |
Mounting Screw Size | M2 x 0.4mm |
Product Weight | 4.15oz |
Encoder: Cycles Per Revolution (Motor Shaft) | 3 |
Encoder: Cycles Per Revolution (Output Shaft) | 1,365.555 |
Encoder: Countable Events Per Revolution (Motor Shaft) | 12 |
Encoder: Countable Events Per Revolution (Output Shaft) | 5,462.22 |
Encoder Type | Relative, Quadrature |
Encoder Sensor Type | Magnetic (Hall Effect) |
Encoder Sensor Input Voltage Range | 2.4 - 26V |
Encoder Sensor Output Pulse Amplitude | ~= Sensor Input Voltage |
