Voltage (Nominal) | 12V |
---|---|
Voltage Range (Recommended) | 6V - 12V |
Speed (No Load)* | 900 rpm |
Current (No Load)* | 120mA |
Current (Stall)* | 1600mA |
Torque (Stall)* | 9 oz-in |
Gear Ratio | 29.977:1 |
Gear Material | Metal |
Gearbox Style | Straight Cut Spur |
Motor Type | DC |
Output Shaft Diameter | 3mm (0.118") |
Output Shaft Style | D-shaft |
Output Shaft Support | Brass Case |
Electrical Connection | ZH Series JST 6-pin connector (1.5mm Pitch) |
Operating Temperature | -10°C ~ +85°C |
Mounting Screw Size | M1.6 x 0.35mm |
Product Weight | 0.4 oz |
Encoder: Cycles Per Revolution (Motor Shaft) | 3 |
Encoder: Cycles Per Revolution (Output Shaft) | 89.9306 |
Encoder: Countable Events Per Revolution (Motor Shaft) | 12 |
Encoder: Countable Events Per Revolution (Output Shaft) | 359.7222 |
Encoder Type | Relative, Quadrature |
Encoder Sensor Type | Magnetic (Hall Effect) |
