Stroke | 3.9" |
---|---|
Pulse Amplitude | 3 - 5 V |
Operating Temperature | -10°C ~ +50°C |
Motor Type | Brushed DC |
Feedback Style | 11 KΩ / inch |
Wire Length | 300 mm |
Weight | 2.45 oz |
Wire Gauge | 26 AWG |
Voltage Range (Recommended) | 4.5V - 7.5V |
Speed (No Load)* | 6.5 mm per second |
Connector Type | Male Servo Connector |
Gear Ratio | 210:1 |
Dynamic Thrust* | 80 N |
Static Load | 200 N powered on, 45 N powered off |
Current Drain (No-Load)* | 7.2 mA |
Current Drain (Stall)* | 460 mA |
IP Rating | IP54 |
Duty Cycle | 20% |
Potentiometer Linearity | Less than 2.00% |
